E-Cleaner Mini

Hydroscand - E-Cleaner Mini, when access is important

The e-cleaner Mini system effectively cleans all types of hoses and tubes with a minimum of effort and time. The system uses a foam plug which is propelled through the hose/tube by compressed air and the outer diameter of the plug approx. 20% larger than the inner diameter of the hose/tube. Hose nozzles are available from 3/16" to 1" and tube nozzles from 4 mm. to 30 mm.

TECHNICAL DATA
Hose capacity: 3/16" - 1"
Tube capacity,ID: 4 -30 mm
Max length: Up to 100 metre
Purity level ISO4406: ISO 20/17
Air pressure: min.6 bar

DESIGNATION
9035-01-01: E-Cleaner MiniJet pistol, excl. nozzles
9035-00-00: E-Cleaner MiniJet complete case, incl 9 pcs hose nozzles
9035-00-01: E-Cleaner MiniJet complete case, incl 9 pcs optional tube nozzles

DIMENSIONS
Sizes are avaliable on request

HOSE NOZZLES
Material: Thermoplastic, black
Sizes are avaliable on request

TUBE NOZZLES
Material: Thermoplastic, black
Sizes are avaliable on request
